Dryer Hose
and Suction Hose |
|
Dryer (DH)
Dryer - Insulated (IDH)
Return Air Dryer - Return Air (RDH)
Suction - Abrasion Resistant (USH)
Suction - Heavy Duty (ESH)
Suction - Super Heavy Duty (Tigerflex: WE and WT Series)
Dryer Hose
DH Series
Fiberglass/Silicone coated for hot or cold air handling, fume removal or ventilation from dryers, tanks or enclosures. Low pressure handling of gaseous materials. Resists extreme temperatures, fungi and ozone. Fair resistance to alkalis, water, oils and solvents. Very flexible at low temperatures. Odor free in hot air service. DH-4001 Single Ply Series:
Tube: Single Ply Silicone Fiberglass
Reinforcement: Spring Steel Wire Helix
Temperature Range: -65°F to +550°F
Colors: Available in Orange Only
Sizes: Available from 3/4" to 6" I.D.
Packaging: Sold by the 12' section only
DH-2001 Double Ply Series:
Tube: Double Ply Silicone Fiberglass
Reinforcement: Spring Steel Wire Helix
Temperature Range: -80°F to +600°F
Colors: Available in Orange Only
Sizes: Available from 3/4" to 12" I.D.
Packaging: Sold by the 12' section only. |
 |
| DH-4001 Single Ply |
|
DH-2001 Double Ply |
PART
NO. |
HOSE
I.D. |
WORM GEAR
CLAMP |
|
PART
NO. |
HOSE
I.D. |
WORM GEAR
CLAMP |
| DH-4001-0075 |
3/4" |
PSHC-10 |
|
DH-2001-0075 |
3/4" |
PSHC-10 |
| DH-4001-0100 |
1" |
PSHC-12 |
|
DH-2001-0100 |
1" |
PSHC-12 |
| DH-4001-0125 |
1-1/4" |
PSHC-16 |
|
DH-2001-0125 |
1-1/4" |
PSHC-16 |
| DH-4001-0150 |
1-1/2" |
PSHC-20 |
|
DH-2001-0150 |
1-1/2" |
PSHC-20 |
| DH-4001-0175 |
1-3/4" |
PSHC-24 |
|
DH-2001-0175 |
1-3/4" |
PSHC-24 |
| DH-4001-0200 |
2" |
PSHC-28 |
|
DH-2001-0200 |
2" |
PSHC-28 |
| DH-4001-0225 |
2-1/4" |
PSHC-32 |
|
DH-2001-0225 |
2-1/4" |
PSHC-32 |
| DH-4001-0250 |
2-1/2" |
PSHC-36 |
|
DH-2001-0250 |
2-1/2" |
PSHC-36 |
| DH-4001-0275 |
2-3/4" |
PSHC-40 |
|
DH-2001-0275 |
2-3/4" |
PSHC-40 |
| DH-4001-0300 |
3" |
PSHC-44 |
|
DH-2001-0300 |
3" |
PSHC-44 |
| DH-4001-0325 |
3-1/4" |
PSHC-48 |
|
DH-2001-0325 |
3-1/4" |
PSHC-48 |
| DH-4001-0350 |
3-1/2" |
PSHC-52 |
|
DH-2001-0350 |
3-1/2" |
PSHC-52 |
| DH-4001-0375 |
3-3/4" |
PSHC-64 |
|
DH-2001-0375 |
3-3/4" |
PSHC-64 |
| DH-4001-0400 |
4" |
PSHC-64 |
|
DH-2001-0400 |
4" |
PSHC-64 |
| DH-4001-0500 |
5" |
PSHC-72 |
|
DH-2001-0500 |
5" |
PSHC-72 |
| DH-4001-0600 |
6" |
- |
|
DH-2001-0600 |
6" |
- |
| DH-4001-0800 |
8" |
- |
|
DH-2001-0800 |
8" |
- |
| DH-4001-1000 |
10" |
- |
|
DH-2001-1000 |
10" |
- |
| DH-4001-1200 |
12" |
- |
|
DH-2001-1200 |
12" |
- |
|
|
Insulated Dryer Hose
IDH Series
For use when heat loss is a problem.Inner Core Duct: 2-ply Silicone/Fiberglass
Outer Duct: Black Neoprene
Insulation: 1" thick Fiberglass between inner and outer duct, fortified with an extra wrap or urethane foam. If space is a concern, ½" insulation is also available by special order.
Temperature Range: -65°F to +500°F
Colors: Available in Black Only
Sizes: Available from 1½" to 6" I.D.
Packaging: Sold by the 12' section only. |
 |
PART
NO. |
HOSE
I.D. |
| IDH-0150-1 |
1-1/2" |
| IDH-0134-1 |
1-3/4" |
| IDH-0200-1 |
2" |
| IDH-0250-1 |
2-1/2" |
| IDH-0300-1 |
3" |
| IDH-0400-1 |
4" |
| IDH-0500-1 |
5" |
| IDH-0600-1 |
6" |
|
|
Return Air Dryer Hose
RDH Series
RDH Single-Ply Series:
Tube: 1-ply Neoprene Coated Fiberglass
Reinforcement: Fiberglass Cord
Temperature Range: -40°F to +350°F
Colors: Available in Black Only
Sizes:
Available from 1" to 12" I.D.
Packaging: Sold by the 12' section.
RDH2 Double-Ply Series:
Tube: 2-ply Neoprene Coated Fiberglass
Reinforcement: Spring Steel Wire Helix
Temperature Range: -65°F to 300°F
Colors: Available in Black Only
Sizes: Available from 1" to 12" I.D.
Packaging: Sold by the 12' section. |
 |
|
RDH Single Ply |
RDH2 Double Ply |
PART
NO. |
HOSE
I.D. |
WORM GEAR
CLAMP |
PART
NO. |
HOSE
I.D. |
WORM GEAR
CLAMP |
| RDH-1 |
1" |
PSHC-10 |
RDH2-1 |
1" |
PSHC-10 |
|
RDH-114 |
1-1/4" |
PSHC-16 |
RDH2-114 |
1-1/4" |
PSHC-16 |
|
RDH-112 |
1-1/2" |
PSHC-20 |
RDH2-112 |
1-1/2" |
PSHC-20 |
|
RDH-134 |
1-3/4" |
PSHC-24 |
RDH2-134 |
1-3/4" |
PSHC-24 |
| RDH-2 |
2" |
PSHC-28 |
RDH2-2 |
2" |
PSHC-28 |
|
RDH-212 |
2-1/2" |
PSHC-36 |
RDH2-212 |
2-1/2" |
PSHC-36 |
| RDH-3 |
3" |
PSHC-44 |
RDH2-3 |
3" |
PSHC-44 |
|
RDH-312 |
3-1/2" |
PSHC-52 |
RDH2-312 |
3-1/2" |
PSHC-52 |
| RDH-4 |
4" |
PSHC-64 |
RDH2-4 |
4" |
PSHC-64 |
|
RDH-5 |
5" |
PSHC-72 |
RDH2-5 |
5" |
PSHC-72 |
| RDH-6 |
6" |
- |
RDH2-6 |
6" |
- |
|
RDH-7 |
7" |
- |
RDH2-7 |
7" |
- |
| RDH-8 |
8" |
- |
RDH2-8 |
8" |
- |
|
RDH-9 |
9" |
- |
RDH2-9 |
9" |
- |
| RDH-10 |
10" |
- |
RDH2-10 |
10" |
- |
|
RDH-12 |
12" |
- |
RDH2-12 |
12" |
- |
|
|
Heavy Duty Suction Hose
ESH Series
If you change hose with every color change, then this economical hose is for you. Heavy duty PVC, food grade, crystal clear, clockwise-spiral, material handling hose. Designed with a corrugated construction for added flexibility and a smooth bore allowing for unrestricted flow. PVC compound complies with applicable FDA and 3A Sanitary Standards. Uses clockwise spiral double bolt clamps.
Series ESH Hose is available with or without embedded static (Grounded) wire.
Tube: PVC
Temperature Range (Grounded): +15°F to +150°F
Static Condition Service Temperature (Non-Grounded): -4°F to +150°F
Dynamic Condition Service Temperature (Non-Grounded): +14°F to +104°F
Colors: Available in Clear Only
Sizes: Available from 1" to 4" I.D.
Packaging: Sold in 25'+ sections and Full Coil only. |
 |
PART
NO. |
HOSE
I.D. |
HOSE
O.D. |
WORKING
PRESSURE
@72°
(psi) |
WORM GEAR
CLAMP |
APPROX.
WT./100' |
| ESH1 |
1" |
1.30" |
50 |
PSHC-20 |
16# |
| ESH114 |
1-1/4" |
1.57" |
45 |
PSHC-20 |
22# |
| ESH112 |
1-1/2" |
1.87" |
45 |
PSHC-28 |
31# |
| ESH134 |
1-3/4" |
2.09" |
45 |
PSHC-32 |
40# |
| ESH2 |
2" |
2.40" |
40 |
PSHC-36 |
48# |
| ESH214 |
2-1/4" |
2.63" |
40 |
PSHC-40 |
57# |
| ESH212 |
2-1/2" |
3.00" |
35 |
PSHC-44 |
70# |
| ESH3 |
3" |
3.56" |
35 |
PSHC-52 |
95# |
| ESH4 |
4" |
4.60" |
30 |
PSHC-72 |
112# |
| ESH39 |
39mm |
47.5mm |
45 |
PSHC-28 |
35# |
| ESH45 |
45mm |
53.1mm |
45 |
PSHC-32 |
40# |
| ESH57 |
57mm |
66.8mm |
40 |
PSHC-40 |
57# |
| Wire Embedded ESH Hose |
PART
NO. |
HOSE
I.D. |
HOSE
O.D. |
WORKING
PRESSURE
@72°
(psi) |
WORM GEAR
CLAMP |
APPROX.
WT./100' |
| ESH114W |
1-1/4" |
1.52" |
50 |
PSHC-20 |
28# |
| ESH112W |
1-1/2" |
1.79" |
50 |
PSHC-28 |
31# |
| ESH134W |
1-3/4" |
2.09" |
45 |
PSHC-32 |
44# |
| ESH2W |
2" |
2.36" |
40 |
PSHC-36 |
52# |
| ESH212W |
2-1/2" |
2.93" |
35 |
PSHC-44 |
81# |
| ESH3W |
3" |
3.50" |
35 |
PSHC-52 |
99# |
| ESH4W |
4" |
4.50" |
35 |
PSHC-72 |
140# |
| ESH39W |
39mm |
45.5mm |
50 |
PSHC-28 |
31# |
| ESH45 |
45mm |
53.1mm |
45 |
PSHC-32 |
44# |
|
|
|
|
Super Heavy Duty Suction Hose
Tigerflex® - WT and WE Series
For your vacuum loader. PVC, food grade, crystal clear, counter-clockwise spiral, material handling hose, designed with a convoluted cover for increased flexibility and a smooth bore to eliminate material build up. PVC compound complies with applicable FDA and 3A Sanitary Standards. Uses counter-clockwise spiral double bolt clamps.Series WE is embedded with a static wire for grounding. WT does not have the static wire.
Tube: PVC
Static Condition Service Temperature: -4°F to +150°F
Dynamic Condition Service Temperature: +14°F to +104°F
Colors: Available in Clear Only
Sizes: Available from 1¼" to 4" I.D.; including 39mm, 45mm and 57mm.
Packaging: Sold in 25'+ sections and Full Coil lengths only. |
WT Series
WE Series
|
|
Tigerflex® Series "WT"
|
PART
NO. |
HOSE
I.D. |
WORKING GEAR
CLAMP |
SPIRAL
BOLT
CLAMP |
| SH114 |
1-1/4" |
PSHC-20 |
SDBC150-CC |
| SH112 |
1-1/2" |
PSHC-28 |
SDBC150-CC |
| SH134 |
1-3/4" |
PSHC-32 |
SDBC2-CC |
| SH2 |
2" |
PSHC-36 |
SDBC2-CC |
| SH214 |
2-1/4" |
PSHC-40 |
SDBC250-CC |
| SH212 |
2-1/2" |
PSHC-44 |
SDBC250-CC |
| SH3 |
3" |
PSHC-52 |
SDBC3-CC |
| SH312 |
3-1/2" |
PSHC-64 |
SDBC4-CC |
| SH4 |
4" |
PSHC-72 |
SDBC4-CC |
Tigerflex® Series "WT"
(Metric) |
PART
NO. |
HOSE
I.D. |
WORKING GEAR
CLAMP |
SPIRAL
BOLT
CLAMP |
| SH39 |
39mm (1.54") |
PSHC-28 |
SDBC150-CC |
| SH45 |
45mm (1.77") |
PSHC-32 |
SDBC2-CC |
| SH57 |
57mm (2.24") |
PSHC-40 |
SDBC250-CC |
|
|
|
|
Tigerflex® Series "WE"
|
PART
NO. |
HOSE
I.D. |
WORKING GEAR
CLAMP |
SPIRAL
BOLT
CLAMP |
| SH114W |
1-1/4" |
PSHC-20 |
SDBC150-CC |
| SH112W |
1-1/2" |
PSHC-28 |
SDBC150-CC |
| SH134W |
1-3/4" |
PSHC-32 |
SDBC2-CC |
| SH2W |
2" |
PSHC-36 |
SDBC2-CC |
| SH214W |
2-1/4" |
PSHC-40 |
SDBC250-CC |
| SH212W |
2-1/2" |
PSHC-44 |
SDBC250-CC |
| SH3W |
3" |
PSHC-52 |
SDBC3-CC |
| SH4W |
4" |
PSHC-72 |
SDBC4-CC |
Tigerflex® Series "WE"
(Metric)
|
PART
NO. |
HOSE
I.D. |
WORKING GEAR
CLAMP |
SPIRAL
BOLT
CLAMP |
| SH39W |
39mm (1.54") |
PSHC-28 |
SDBC150-CC |
| SH45W |
45mm (1.77") |
PSHC-32 |
SDBC2-CC |
| SH57W |
57mm (2.24") |
PSHC-40 |
SDBC250-CC |
|
|
Abrasion Resistant Suction Hose
USH Series
Polyurethane lined, abrasion resistant PVC material handling hose with counter-clockwise spiral. Convoluted cover is made with low temperature, anti-static HMW PVC compounds for sub-zero flexibility. Smooth urethane liner provides resistance to abrasion and eliminates material build up. Uses counter-clockwise spiral double bolt clamps.Tube: PVC
Liner: Polyurethane
Static Condition Service Temperature: -40°F to +150°F
Dynamic Condition Service Temperature: +22°F to +104°F
Colors: Available in Black Only
Sizes: Available in 1½", 2", 2½" and 3" I.D.
Packaging: Sold by the 100' section only. |
 |
|
PART
NO. |
HOSE
I.D. |
WORKING GEAR
CLAMP |
SPIRAL
BOLT
CLAMP |
| USH112 |
1-1/2" |
PSHC-28 |
SDBC150-CC |
| USH2 |
2" |
PSHC-36 |
SDBC2-CC |
| USH212 |
2-1/2" |
PSHC-44 |
SDBC250-CC |
| USH3 |
3" |
PSHC-52 |
SDBC3-CC |
|
PS&E hose is compatible with the following brands: Accuflex, Ace, Armstrong, BDI, delafield, Durodyne, Eaton, Flexcraft, gates, Goodyear, HMD/Thermoid, Jackson Industries, Kord, Kuriyama, Lab Industrial, Lincoln, Nova Flex, NRP Jones, Parker, Parker-Hannifin, Powertrack, Riverbend, Salem-Republic, Senior Flexonics, Swan Hose, TCH, Thermoid, Tifco, Tift, Titan industries, US Hose, Willcox.
